Description
Trigon Advance III and Trigon Advance III Special Edition
The Trigon Advance III is a phono amplifier for MM and MC systems featuring an integrated battery power supply and an external charging unit.
By utilizing pure battery power, the Advance III ensures delicate phono signals maintain their original integrity. This unique design results in an incredibly low noise floor and a highly immersive analogue experience.
For simple operation and high reliability, the front panel displays all operating conditions. Sophisticated software manages the charging and monitoring of the ultra-long-life lead batteries.
Externally accessible switches allow for optimum adjustment of gain, impedance, and capacitance to match various cartridges. The slim design ensures short signal paths by allowing the unit to be placed in the immediate vicinity of the turntable.
Special Edition Model (£2,195.00)
For the ultimate analogue performance, the Special Edition brings a host of upgrades:
- Higher grade, hand-matched discrete components for ultimate high fidelity
- Upgraded power supply
- Solid slate base with spike and isolator feet assembly
- Gold-plated front fascia
Technical Data
| Amplification | 36 – 60 dB (adjustable in 16 stages) |
| Input Impedance | 25 Ohm to 1800 Ohm (31 stages), 47k Ohm (MM) |
| Input Capacity | 60 – 100 pF basic capacity / 47 pF, 100 pF, 147 pF |
| Inputs | 1x RCA |
| Outputs | 1x RCA |
| Frequency Response | 20 Hz – 20 kHz ±0.2 dB RIAA |
| Distortion | < 0.06% |
| Crosstalk | < -96 dbA |
| Warranty | 3 years |
| Dimensions | 200mm x 58.5mm x 320mm |
