Description
Over more than 45 years experience in audio, Charisma Audio have collected the solid ideas which inspire the design and manufacture of our accessories. Using premium materials, these not only look attractive but also show striking performance.
Charisma Audio Signature YYZ Moving Coil Cartridge
A money-no-object expression of Charismas art, featuring a diamond cantilever and stylus with class leading heat dissipation for sound quality that is exquisite, with a perfect balance and flat signal response. Tracks at only 1.45 grams. First with Diamond cantilever, super fine line contact nude diamond stylus, yellow rosewood body.
Technical Specifications
- Cartridge Weight: 8 g
- Cartridge body: yellow rosewood
- Cantilever: diamond
- Stylus: micro fine line contact diamond
- Vertical Tracking Angle: 20 degrees
- Coil: pure iron square coil with custom made alloy wiring
- Output Voltage: 0.35 mV at 3.54 cm/sec.
- Internal Impedance: 6 ohms
- Frequency Response: 2030,000 Hz ± 1 dB
- Channel Balance: better than 0.5 dB
- Channel Separation: better than 30 dB
- Dynamic Compliance: 10 um/mN
- Recommended Loading: 100330 ohms
- Recommended Tracking Force: 1.4 g ± 0.1 g
- Optimum Tracking Force: 1.45 g
- Tracking Ability at 315 Hz / 2 g: 80 uM
- Recommended Tonearm Mass: medium
- Break-in Period: 50 hours
